Description
Turning Point Hub Kit #206 (Manufacturer Part Number: 11100601) is a drop-in installation kit engineered for Evinrude, Johnson, and Suzuki outboards equipped with a 2.5-inch gearcase and a 10-spline prop shaft. This specialized one-piece hub system incorporates a marine bronze splined spindle over-molded with a glass-filled polymer cushion to dampen shift shock, eliminate propeller chatter, and safeguard the lower unit gear train during impacts.
Engine Compatibility Details
The #206 kit matches specific small-horsepower outboards. It is highly variant-dependent and fits the following configurations:
- Evinrude & Johnson: 9.9 HP and 15 HP 4-Stroke models manufactured from 2002 to present (10-spline models).
- Suzuki (Type M):
- DT 2-Stroke: 9.9 HP (1983–1987 models only) and 15 HP / 15C variants.
- DF 4-Stroke: 8A, 9.9, 9.9A, 9.9B, 15, and 20 HP models (2012 to present).
- Exclusion: This kit will not fit Suzuki DT 8C and 9.9C models produced between 1988 and 1997.
Core Technical Specifications & Design Benefits
- Propeller Housing Cross-Compatibility: The outer geometry of the hub adapts Turning Point's Hustler (aluminum) and Express (stainless steel) housings to your motor. It can also fit alternative exchangeable-hub propeller housings from brands utilizing the Mercury Flo-Torq II, Michigan Wheel XHS, or Solas Rubex hub footprints.
- Drivetrain Protection: The inner high-tech polymer acts as a sacrificial cushion during prop strikes. This prevents spun hubs and isolates vibration without the risk of plastic stress cracking.
- Exhaust Optimization: Features a small-diameter design that maximizes the hub's internal cavity space, encouraging cleaner exhaust gas flow and maximizing engine horsepower output.
- Manufacturer Lifetime Warranty: Turning Point covers these MasterGuard hub inserts with a lifetime replacement warranty for recreational boaters, covering the hub component even if the outer propeller housing is completely destroyed.
Hardware Pack Contents
The kit contains the following necessary components for completing the installation over your existing factory thrust hardware:
- One-Piece MasterGuard Hub Assembly (10-spline inner brass/bronze core)
- Aft Propeller Nut Spacer / Washer
- Step-by-Step Installation Directions
(Note: Installation requires reusing your motor's original OEM forward thrust washer and cotter-pin prop nut assembly)
